High temperature circulating oil bath thermostatic circulation water bath

  • 소개

  • 명세서


High temperature circulating oil bath

High temperature circulating oil bathHigh temperature circulating oil bath

High temperature circulating oil bath

High temperature circulating oil bathHigh temperature circulating oil bath

High temperature circulating oil bath

High temperature circulating oil bath


Model

GSC-5L

GSC-10L

GSC-20L

GSC-30L

GSC-50L

GSC-100L

GSC-150L

Bath volume

5L

10L

20L

30L

50L

100L

150L

Heating power

1.5kW

2kW

3kW

4.5kW

5kW

9kW

9kW

Circulating power

100W

280W

370W

Flow

20L/min

30L/min

42L/min

Lift

4~6m

10~12m

28m

Temperature

Water:RT~99℃

Oil:RT~200℃

Temperature control

PID control, LED digital display

Temp accuracy

±1℃

Voltage

220V/50Hz,Single phase

380V/50Hz,Triphase

Ambient pressure

86kPa~106kPa

Ambient temperature

0~50℃

Ambient humidity

45%~85%RH

Circulating medium

Water(distilled water/ deionized water)

Oil(Simethicone,viscosity≤100cts)

Connecting pipe

Viton pipe or stainless steel bellows

Size(cm)

48*38*63

55*45*78

68*55*84

65*80*94

103*88*122
